| MODEL | 24-HP-V63-R08 |
| PRINCIPLE OF OPERATION | Hydraulic Driven cylinder compacts a sample. |
| APPLICATIONS | Preparing Pellets for XRF analysis, Preparing pellets for fire test in ceramic industries. |
| INDUSTRY | Cement, Steel, Power Plant, Mining, Ceramic, Glass, Pharmaceutical and Academic institutes. |
| TIME OF ONE PRESSING SEQUENCE | 30Sec/For Limestone 10 seconds holding time, since the material having better binding property |
| RAM SPEED | 3.2 mm / Sec (During Compression Stroke) 5.5 mm / Sec (During Return Stroke) |
| PUMP CAPACITY | 4 LPM@250 Bar. |
| DIGITAL SETTING OF COMPRESSION FORCE | 5 Tons to 40 Tons. |
| DIGITAL SETTING OF HOLD TIME | 0 to 300 Seconds. Digital Setting of Intervals of decompression & return back to zero Position. |
| POWER OF HYDRAULIC PUMP | 3 HP (For 40 tons) |
| SAFETY FEATURES | Safety interlock and automatic Pump Shut-Off safety valve is provided for safe operation, sensor plates to avoid empty cycle and over shooting. Protection from Pressing without DIE, Spring Guard, Emergency STOP SWITCH |
| WEIGHT | 450 KG |
| MOTOR | 415 V, AC Motor, 3 HP, 1440 rpm |
| ELECTRICAL SUPPLY | 3 ϕ/440 V/4 POLE 16 A MCB/1700 WATTS |
| WARRANTY | 12 Months from Date of Installation and 12 Months from Date of Dispatch. Whichever comes Early |
| MANUFACTURING ADDRESS | RAX UNIQUE TECHNOLOGIES, GSTIN-33HCR5134Q1ZZ, No-145,1st floor, Tasiow Nagar, Ramamoorthy 3rd Main Road, Pazhanthandalam, Thirumudivakkam, Chennai, Pincode-600044, Kancheepuram |
